QA Derpartment
- Brown & Sharpe (auto) coordinate measuring machine
- Aberlink (manual) coordinate measuring machine
- 2D projector
- 2D digital height machine *2 sets
- Salt spray testing equipment *2 sets
- Optical emission spectrometer
- Spectrophotometer
- Precision gauge block
- Surface roughness meter
American Brown & Sharpe triple dimension coordinate measuring machine
- Model: MicroVal PFx 454 (system tutor for windows)
- Operation method: manual, joystick control, CNC programming control
- Working travel: 458mm X, 510mm Y, 406mm Z
- Size: 914mm X, 979mm Y, 2413mm Z
- Precision: VDI_VDE 2617 standard
- U1: 2.8+3.0 L/1000um
- U3: 3.0+4.0 L/1000um
- Maximum weight: 227 kg
- Machine weight: 350 kg
Baty Venture
- The model type: desktop, high-rigid V-slide measurement-driven design to Taiwan, Tri-axial DC SERVO MOTERS
- Venture Full CNC XYZ host signal processing circuit
- Joystick controller high-performance
- Fusion Vision system Windows measurement software (contact and non-contact two-in-one)
- Actuator way: CNC / MJC model
- Measurement range: 640mmX, 570mmY, 170mmZ
- Accuracy: X, Y u95: (2.5 + L / 100) μm
- Z u95: (3.0 + L / 100) μm for touch probe
- Working Platforms: made in granite, glass table for precision
- Bearing: used precision air bearings
- Material: Y, Z are aerospace aluminum alloy material, the stability of the high -
- Control mode: control rocker (MJC), direct computer control (DCC)
- Measurement system: high-resolution 0.5 μm optical ruler
- Environmental Requirements: Temperature - 20 ± 2.0 ℃
- Relative Humidity: - 30 ~ 80%
- Displacement speed: 500mm/sec
- Operating requirements: temperature range - 10 ℃ ~ 35 ℃
- Power: 110VAC ± 10% / 50Hz
